TRA36034-1BLUEX TRAXXAS 1/10 Scale Classic BigFoot Monster Truck 2wd – BlueX

TRA36034-1BLUEX TRAXXAS 1/10 Scale Classic BigFoot Monster Truck 2wd – BlueX

Note: Graves RC Coupons are not applicable with this product



Features:

• Scale Replica Body of the BIGFOOT^® No. 1 Truck
• 4-amp DC Peak Detecting Fast Charger
• Traxxas 7-cell NiMH battery with iD^TM
• Traxxas TQ 2.4GHz radio system
• Waterproof electronics permit driving in water, mud and snow.
• Traxxas #6519 3-channel micro receiver.
• Waterproof receiver box.
• High-torque Waterproof Traxxas #2056 steering servo.
• Monstrous 4-inches of center ground clearance.
• The included optional 19-tooth pinion gear pushes BIGFOOT^®
  to speeds over 30mph.*
• Powerful Titan^® 12T 550 modified motor with internal cooling fan.
• High-performance waterproof XL-5™ Electronic Speed Control.
  • Innovative watersealed design
  • Three Drive Profiles
    • Sport Mode – Forward / Brake / Reverse
    • Race Mode – Forward / Brake
    • Training Mode™ – 50% Forward / Brake / 50% Reverse (patented)
  • 12-Turn motor limit for 550 size motors
  • 15-Turn motor limit for 540 size motors
  • Integrated on/off switch
  • Traxxas EZ-Set^® one-button setup
  • LiPo and NiMH compatible with two-stage low-voltage detection
  • High-efficiency MOSFET transistors
• Speed control and receiver are securely screwed to the chassis.
• Efficient Magnum 272™ three-gear transmission with ball bearings.
• Sealed gearbox protects the transmission with beefed up motor
  guard for extra protection.
• Torque-Control™ slipper clutch system.
• External gear cover with easy slipper access.
• Reliable planetary gear differential.
• Efficient telescoping U-joint driveshafts.
• Fiber-composite monocoque chassis.
• Easy access battery compartment.
• Fully adjustable Ultra Shocks™ with X-ring technology.
• Powder-coated shock springs feature a new responsive spring rate.
• Durable solid camber links eliminate the need for adjustment.
• Captured rod ends won’t pop off for superior durability.
• Bright Chrome Dish dual-profile wheels
• Pre-glued Terra-Groove 2.2″ tires
• ProGraphix^® multi-colored painted body.
• Unparalleled Traxxas support parts availability.

Specifications

Length: ­ 16.25 inches (413 mm) Front Track: ­ 12.75 inches (324 mm) Rear Track: ­ 12.75 inches (324 mm) Weight: ­ 65.3 ounces (1.85 kg) Height (overall): ­ 9.5 inches (241 mm) Wheelbase: ­ 10.63 inches (270 mm) Front Shock Length: ­ Long Rear Shock Length: ­ XXLong Front Tires: ­ Terra-Groove 2.2″ Rear Tires: ­ Terra-Groove 2.2″ Front Wheels: ­ Bright Chrome Dish (Dual Profile) Rear Wheels: ­ Bright Chrome Dish (Dual Profile) Electronic Speed Control: ­ XL-5™ Electronic Speed Control Motor (electric): ­ Titan® 12T 550 (12-Turn) Steering Servo: ­ #2056 High Torque Waterproof Transmitter: ­ TQ 2.4GHz Radio Receiver: ­ #6519 3-Channel Micro Gear Ratio (internal): ­ 2.72 (final drive: 12.34) Differential Type: ­ Planetary Gear Pitch: ­ 48-Pitch Transmission: ­ Magnum 272™ Steering: ­ Single Point Chassis Type: ­ Modified Tub Chassis Material: ­ Composite Nylon Top Speed: ­ 30+mph** Skill Level: ­ 1 *Battery Tray Dimensions: ­ 138 mm x 46 mm x 26 mm Included Charger: ­ 4-amp DC Peak Detecting Fast Charger Included Batteries: ­ Traxxas 7-cell NiMH battery with iDTM Required Batteries: ­ 4 “AA” (transmitter) *Battery expansion kit available (#3725X). **With 7-cell battery and included optional 19-tooth pinion gear. 25+mph with 6-cell battery and stock installed pinion.

XL-5 (WATERPROOF) ESC SPECIFICATIONS

Input voltage: ­ 4-7 Cells (4.8 to 8.4 Volts DC) Case Size: ­ 31 mm x 55 mm x 15.5 mm Weight: ­ 2.44 ounces Motor Limit: ­ 15-turns** (540 Size) 12-turns** (550 Size) On Resistance Forward: ­ 0.007 Ohms On Resistance Reverse: ­ 0.014 Ohms BEC Voltage: ­ 6.0 VDC BEC Current: ­ 1A Power Wire: ­ 14 Gauge / 5 inches Input Harness Wire: ­ 26 Gauge / 9 inches PWM Frequency: ­ 1600 Hz Low Voltage Detection (LVD): ­ 2-Stage indicators, switchable (on or off) Thermal Protection: ­ Thermal shutdown Profile selection: ­ Sport Mode:     100% FWD, 100% brakes, 100% REV Race Mode:     100% FWD, 100% brakes, no REV Training Mode:*     50% FWD, 100% brakes, 50% REV Single-button setup: ­ Yes, Traxxas EZ-Set®
