SIGRC85 SIG SEALANE 40SIZE KIT

SIGRC85 SIG SEALANE 40SIZE KIT

THIS IS AN OVERSIZE ITEM THAT DOES NOT QUALIFT FOR FREE SHIPPING



Taxi gently away from the dock and head for open water. Increase power and watch the water spray behind you as the hull lifts smoothly off the water. Gentle, graceful, responsively solid. Then turn-it-on; loops, rolls, even inverted flight! You would never think this was a seaplane. Settle back for a smooth touchdown into the sunset and taxi back to the dock with solid, positive control, even in crosswinds.

The Sealane features a strong one-piece removable wing allowing easy access to all your radio gear.

The Sealane is the perfect choice for your first-time seaplane. The Sealane builds quickly with precision laser cut wood parts; full-size rolled plans and illustrated assembly manual leaving nothing to the imagination, even for the novice builder. Includes a quality hardware package.

The high mounted forward facing engine pylon keeps your engine high and dry.

While the SeaLane is no landlubber, we include optional instructions showing the installation of a fixed gear tail dragger landing gear. Simply add the main and tail wheel assemblies (not included), detach the tip floats and burn up the skies at your local field. The SeaLane is the perfect choice for your first-time seaplane. Bring home all the thrills and excitement of aero-marining home today.



This is no ordinary Build It Yourself airplane kit. All wood parts in the SeaLane are precision laser cut from the finest hand selected balsa and plywood. Building time is kept to a minimum as the laser parts go together fast and accurately; fast enough to rival the assembly time of some ARF airplanes. A quality hardware package, full size rolled plans and a fully illustrated construction manual leave nothing to the imagination, even for the novice builder.

Optional Landlubber Landing Gear
(Main and tail wheel not included)

The SeaLane features a one-piece, removable wing, allowing easy access to all your radio gear. The forward facing pylon mounted engine keeps your power plant high and dry. While the SeaLane is no landlubber, we include optional instructions showing the installation of a fixed gear tail dragger landing gear. Simply add the main and tail wheel assemblies (not included), detach the tip floats and burn up the skies at your local field. The SeaLane is the perfect choice for your first-time seaplane. Bring home all the thrills and excitement of aero-marining home today.

Features:

• 100% laser cut parts
• Builds fast
• Quality hardware package
• Full size rolled plans
• Illustrated step-by-step construction manual
• Removable one piece wing
• High mounted forward facing engine pylon
• Removable tip floats
• Optional fixed landing gear

Specifications:

Wingspan: 60.5 in. 1537 mm
Wing Area: 674.2 inﾲ 43.5 dmﾲ
Fuselage Length 63.4 in. 1610 mm
Flying Weight: 6 to 7 lbs. 2720 – 3175 g
Required Engine: .40-.46 inﾳ (6.5 – 7.5 cmﾳ) 2-Stroke Glow
.40-.50 inﾳ (6.5 – 8.2 cmﾳ) 4-Stroke Glow
Radio Required: 4 Channel, 4 Standard Servos

Set Up Specifications:

Elevator		1/2	inch	13	mm	Up and Down
Rudder		1  1/4	inch	32	mm	Right and Left
Ailerons		7/16	inch	11	mm	Up and Down
Center of Gravity		3  1/4	inch	83	mm	From leading edge
Dihedral			degrees		degrees
Incidence		+  degree wing,  degree stabilizer
Engine Offset		0 degree down, 0 degree right

Accessories:

Main Wheels (option)		3	inch	76	mm	2
Tail Wheels (option)		1	inch	25	mm	1
Fuel Tank		8	ounce	237	cc	1
Spinner		2.25	inch	57	mm	1
Covering		2 rolls depending on trim scheme

Manuals:

SIGRC85-Manual-English
