HMXM3000 HELI-MAX MX 400 BRUSHLESS ESC 25A

HMXM3000 HELI-MAX MX 400 BRUSHLESS ESC 25A



HELI-MAX MX 400 BRUSHLESS ESC 25A

Features:

• High Efficiency
• BEC
• Low Weight
• Compact Size
• Automatic cut-off
• Auto-detection of all types and number of cells
• Over Temperature protection
• Brake non-active/active setting allows for hard start or
• soft start modes
• Universal radio connector for use with Futaba, JR, Hitec & Airtronics

Includes:

One 25A Brushless Electronic Speed Control
One instruction sheet

Requires:

Male & Female Bullet connectors for Brushless motor hook-up
One Battery Connector

Specifications:

Length: 1.5″ (38mm)
Width: 0.95″ (24mm)
Thickness: 0.24″ (6mm)
Motor wire lead length: 4″ (102mm) (18AWG wire)
Battery wire lead length: 3.5″ (89mm) (16AWG wire)
Radio wire lead length: 9.5″ (241mm)
Amount of cells(NiCd/NiMH): 6-10 cells
Amount of cells(LiPo): 2-3 cells
Max current: 25A
BEC output: 5.3V
