EFL16575 E-flite Ultimate 3D 950mm PNP

EFL16575 E-flite Ultimate 3D 950mm PNP

THIS ITEM DOES NOT QUALIFY FOR FREE SHIPPING

Note: Graves RC Coupons are not applicable with this product



FEATURES

Construction: Composite-reinforced, hollow-core EPO, beveled hinges for high-angle deflection, vortex generators also enhance performance and handling for mild to wild flying
Wings: Tool-free installation, secures to fuselage with thumb screws
Electronic Speed Control: Spektrum Avian wIC3 connector
Motor: BL10 Brushless outrunner
Servos: Four 9g high torque metal gear
Propeller: 11.6 X 6
Landing Gear: Fixed with steerable tailwheel



INCLUDES

(1) E-flite PNP (Plug-N-Play) Ultimate 3D 950mm
(1) Spektrum Avian 60A Brushless Smart ESC
(1) Brushless Outrunner Motor
(4) High-Torque Metal-Geared Servos
(1) Instruction Manual



REQUIREMENTS

Transmitter and Receiver: Full-range 5-7+ channel Spektrum
DSMXDSM2 compatible
LiPo Battery: 3S 11.1V, or 4S 14.8V 1800-2700mAh wEC3 or IC3 Connector
Compatible LiPo charger and charging bag



SPECIFICATIONS

Length: 42.6 in (1082.3mm)
Wingspan: 37.6 in (954.4mm)
Wing Area: 519 sq in (33.5 sq dm)
Wing Loading: 12.5 ozsq ft, 13.3 ozsq ft
Flying Weight: 45 – 48oz (1270 – 1360g)
Center of Gravity, CG: 3.3 – 3.8 (85 – 96mm)from leading edge of top wing at center
Control Throws Low Rate High Rate
Aileron 0.55 in (14mm) 1.1 in (27mm)
Elevator 1.1 in (27mm) 2.2 in (55mm)
Rudder 1.4 in (35mm) 2.7 in (70mm)
Airfoil: Symmetrical
Approximate Assembly Time: Less than 1 hour

MANUALS

ELF16575-Instruction-Manual-English
